Mining Conveyor System Coal Mine Used Durable Inblock Casting No Welding Transporting Machine 3D Printing Scraper Conveyor Line Pan

Basic Info.

Warranty	1 Year
Color	Blue
Customized	Customized
Condition	New
After-sales Service	Yes
Breaking Force	More Than 2 Times of Welded
Abrasive Resistance	1.6 to 2
Probability of The Chain Cracking	Low
Service Life of The Afc Pan	More Than 2 Times of Welded
Load of The Motor	0.7 to 0.8
Tensile Strength of Ledge	More 1200 MPa
Material of Middle and Board	High Strength Durable Alloy
Material of Ledge	High Strength Durable Alloy
Abrasive Resistance of Ledge	3 to 5 Times
Transport Package	Standrard by Contract
Specification	630-1400 series
Trademark	JK
Origin	Shijiazhuang, Hebei, China
HS Code	8430412200
Production Capacity	500

Product Description

JIKAI Technology Company is ProfessionalManufacturer of Underground Mining Equipment

Scraper conveyor---AFC pan (Armored Face Conveyors Pan)
Product Introdction:

The inblock casting scraper conveyor is the fifth technological revolution. It has been rated as "international leading level" by experts in the coal industry (2 invention patents, 5 utility model patents and 5 provincial and municipal awards). It has been awarded as a national key new product by the Ministry of science and technology, the Ministry of environmental protection and the development and Reform Commission. In 2018, the inblock cast scraper conveyor won the first prize of science and technology of China's coal industry. Our company presided over the preparation of China's first energy industry standard for inblock casting scraper conveyor (Nb / T 10384-2019), which was officially promulgated and

implemented on July 1, 2020. The products have been widely used in major domestic coal mining groups such as Datong Coal Group, Huainan Mining, Pingmei Group, Yitai Group, Yongmei Group, and are exported to Russia, Iran, Poland and other major coal-producing countries in the world.

Technical Features:

The first in the inblock casting technology industry, it is the first choice of scraper conveyor for fully mechanized mining face.

High strength, high wear resistance, corrosion resistance and long service life, which is twice longer than that of traditional scraper conveyor;

Corrugated design can save energy and reduce consumption, and the operating power of the whole machine is 10% ~ 30% lower than that of the traditional scraper conveyor.

Technical features of intelligent 3D molding inblockl casting scraper conveyor.

The intelligent 3D molding inblock casting scraper conveyor is equipped with an industry-leading intelligent control system, which is suitable for a full range of scraper conveyor products. The centralized control center controls and monitors the scraper conveyor, transfer machine, crusher, belt conveyor, self moving device, etc. Ten functions can be realized:

Sequential start and stop, emergency stop and lock;

Smart start;

Automatic chain tension relaxation and chain breaking protection;

Coal quantity monitoring system;

Intelligent speed regulation;

Power unit operation status monitoring;

Power unit operating status health diagnosis, fault early warning protection;

Interlocking and centralized control between the chute and the equipment of the working face;

Support the remote control of the third-party host computer;

Automatic data transmission in the central control center.
Parameters:

Product Series	Installed Power(kW)	Conveying Capacity(t/h)	AFC Pan Inside width(mm)	Design Maximum Length(m)	Scraper Chain Type	Line Pan Structure
630 Series	2×(110~200)	250~450	590(580)	100,150	Single chain / medium double chain	Inblock Casting Line Pan
730 Series	2×(132~250)	450~700	690(680)	100,150,200	Single chain / medium double chain	Inblock Casting Line Pan
764 Series	2×(200~400)	700~1000	724	150,200	Medium double chain	Inblock Casting Line Pan
830 Series	2×(250~400)	1200	780	150,200	Medium double chain	Inblock Casting Line Pan
800 Series	2×(315~525)	1200~1500	800	150~250	Medium double chain	Inblock Casting Line Pan
900 Series	2×(400~855)	1500~2000	900	150~300	Medium double chain	Inblock Casting Line Pan
1000 Series	2×525~3×1000	1800~3000	1000	150~300	Medium double chain	Inblock Casting Line Pan
1200 Series	2×(700~1200)	2500~3000	1200	250~300	Medium double chain	Inblock Casting Line Pan
1250 Series	3×(855~1500)	3000~3500	1250	300~400	Medium double chain	Inblock Casting Line Pan
1400 Series	3×(1200~1600)	4000	1400	400	Medium double chain	Inblock Casting Line Pan

At present, our company has built an advanced R&D system:Since 2007, the company has realized the network and digitization of R&D and design work;3D solid design and finite element analysis;Implemented product data lifecycle management (PLM);project workflow management; the integration of PLM system and ERP system;the paperless application of drawings and all technical data.For example: 3D integral casting scraper conveyor not only greatly improves the service life of the scraper, but also promotes the intelligent construction of fully mechanized mining;Anti-gas and anti-groundpressure automatic drilling rig, equipped with remote control and video monitoring system, with real-time data collection functions, with one-key drilling function and anti-stucking functions, suitable for groundpressure prevention;The national III standard explosion-proof diesel engine monorail crane locomotive realizes multi-point direct transportation of hydraulic supports (48T); the drilling and bolting jumbo can drill with one key, and realize the automatic construction of anchor rods and anchor cable holes.
With firm determination and strong investment, our company has always improved the quality management system, and effectively implemented the quality management system of full participation, full responsibility, whole process control and continuous improvement.We vigorously improve the quality management level to ensure product quality,meet user requirements and be responsible for users.At present, our company has established an advanced quality assurance system.According to the continuously improving quality management requirements, the company has successively developed quality management software that meets the standard requirements, realizing automatic detection and controlling the whole process.
All products have corresponding quality control standards, which are completed simultaneously with design drawings and processes, and are recorded in the information management system.Each product is marked with a unique permanent laser identification code when it is submitted for inspection. The inspection items and records correspond to each identification code, which realizes:1. Unique product quality identification; 2. Traceability of product quality problems; 3. Lifelong responsibility for product quality; 4. The basis for improvement is accurate and sufficient, and the improvement effect is tracked in place.In recent years, we have been rated as Hebei Provincial Enterprise Technology Center, Shijiazhuang Coal Mining Machinery Engineering Technology Research Center, Hebei Coal Mine Safety Equipment Engineering Technology Research Center (in preparation), Hebei Coal Mine Safety Equipment Inspection and Testing Platform (in preparation), The public technology research and development platform for coal mining machinery and equipment of the Ministry of Commerce has been fully affirmed by relevant departments in terms of product research and development, quality inspection, engineering technology transformation, and public
services. In the future, the engineering laboratory will obtain income through technical patents and paid use of new products, undertaking technical engineering research and development tasks for coal mine safety equipment industry, government scientific research funding, technical training and technical services, etc. "The virtuous cycle operation mode, and strive to achieve the sustainable development of the laboratory.
